Brand: Widia / Part #: 2022340

Brand: Widia / Part #: 2022340


Item #: 99728511
Brand: Widia
Model #: 2022340

Product Specifications

Thread Type External
Hand of Holder Right Hand
Compatible Insert Size Code 2
Shank Width/Diameter (mm) 8.00
Toolholder Style NL
Insert Compatibility LT11ER
Coolant Entry Style Code 0-Without Coolant
Insert Holding Method Screw
Shank Height (mm) 8.00
Shank Length (mm) 118.500
Overall Length (mm) 136.0000
Series LT
Multi-use Tool No
Cutting Tool Application Threading
Head Length (mm) 17.50
Maximum Depth of Cut (mm) 4.76
Adjustable Overhang Yes
Back of Bar to Cutting Edge (mm) 11.00
Center to Cutting Edge (mm) 4.00
Insert Inscribed Circle (Decimal Inch) 0.2500
Insert Inscribed Circle (Inch) 1/4
Insert Inscribed Circle (mm) 6.35
Primary Workpiece Material Non-Ferrous Metal; Stainless Steel; Cast Iron; Super-alloys & Titanium; Steel
Primary Workpiece Material Code P; S; K; M; N
Toolholder Material Steel
Manufacturers Catalog Number NL82R
Style LT
Coolant Through No
$123.43
