#WINA563 22" x 22" Fully Automated Bandsaw

Item #: SW15WINA56
Manufacturer: Kasto
Mfg #: WINA5.6

Technical Specifications:
•Band Tension: Hydraulic •Bed Height: 27.56 •Blade Guides: Carbide Interchangeable •Blade Length: 23' 2" •Blade Size: .063 •Blade Speeds: 39.37 - 492.13 •Blade Widths: 2 •Brand Name: Kasto •Capacity (in.): 22 •Cutting Fluid Tank Cap.: 26.42 •Feed Control: Touch screen •Feed System: Ballscrew spindle •Floor Space Required (L x W x H): 64.96 x 129.92 x 89.76 •Index Stroke: 19.69 •Model Number: WINA5.6 •Motor: 7.37 HP •Rectangle Cap.@ 90°: 22 x 22 •Round Cap. @ 90°: 22 •Square Cap. @ 90°: 22 x 22 •Type: Automatic horizontal bandsaw •Vise Type: Hydraulic •Weight: 8378 lbs

Description:
•Automatic high-performance bandsawing machine for serial cutting of solids, tubes and profiles in material qualities which are easy to difficult to cut. The standard precise linear guides (re-circulating ball units with grease lubricated guide carriage) guarantee maximum life. The standard SmartControl offers the optimum operation of the machine. Easy and clearly arranged job entry via job wizard. After making the desired number of cuts, the machine shuts off automatically. By reducing set-up times to a minimum, maximum cutting performances are achieved in automatic mode. The precise drive via ball bearing spindle in material feed guarantees an accurate material length positioning. Frequency controlled spur gear driving with overload monitoring and clamping pressure monitoring for blade clamping and both vices belong to the standard equipment for working processes regarding cutting of individual pieces, smaller and average lot sizes and large series. An infinitely variable electromechanic saw feed with servomotor and ball bearing spindle offers the best conditions for an efficient, sensitive and tool-saving cutting operation. Features: •Customised to the specific application using a modular system design •Quick motion using servo drive and ball screw spindle for the material feed and the linear guided saw frame •Automatic band guide arm adjustment •Quick and easy programming via colour touch screen •SmartControl to ensure high bandsaw blade lifetimes •Incremental feed for cutting batches of short pieces

Shipping Info:
•Commercial Truck - Call for Shipping Charges •Actual Weight - 8360.0000
