2125APC60 20 x 25" Cap. High Production Saw with an NC Programmable Control - USA Tool & Supply

2125APC60 20 x 25" Cap. High Production Saw with an NC Programmable Control


Item #: RF402125APC60
Manufacturer: Marvel
Mfg #: 2125A-PC3-

Technical Specifications:
•Blade Length: 17' 6" •Blade Speeds: 50 - 650 FPM •Blade Widths: 1-1/4 •Brand Name: Marvel •Capacity (in.): 20 x 25 •Model Number: 2125APC360 •Motor: 7.5HP •Rectangle Cap. @ 60°: 20 x 11-1/4 •Rectangle Cap.@ 45°: 20 x 17 •Rectangle Cap.@ 90°: 20 x 25 •Round Cap. @ 90°: 20 •Round Cap.@ 45°: 17 •Type: Vertical Bandsaw •Weight: 6450 lbs

Description:
•48" Servo driven automatic bar feed standard •Twin ball screw bar feed with following support rollers •Full stroke hydraulic vises •Vector control inverter blade drive •Combination carbide & roller bearing blade guides •Easy load blade guides •Full color screen with graphical part programming •Stores up to 500 jobs •Direct force sensing electric feed •Cast iron table and cartridge •Linear bearing on cartridge •Key pad miter and length programming •Dual feed control-rate and force •60 gallon standard coolant system •Full capacity bundling capabilities •2 Year Warranty Parts & Labor •F.O.B. OSKOSH, WI

Shipping Info:
•Commercial Truck - Call for Shipping Charges •Actual Weight - 6450.0000
$146,836.80
