CTHDHM645AL2.5 HYDRAULIC CLUSTER

Item #: HT80CTHDHM64525
Manufacturer: Kurt
Mfg #: CTHDHM645A

Technical Specifications:
*Base Size: 19.685 *Base Thickness: 1.25 *Brand Name: Kurt *Jaw Type: Alumimum *Overall Height: 24.61 *Tower Height: 24.61 *Type: 6" Hydraulic Tower *Weight: 450 lbs

Description:
*This hydraulically operated eight station tower features all-new design for fast loading of parts *All internalized hydraulic piston/nut saves valuable space *Includes all original KURT AngLock precision clamping and iron clad rigid construction for damping vibration *Features: *Hydraulically operated eight station CTHDHLM64 Cluster Tower *Utilizes an all internal hydraulic piston nut to conserve space *Pressure is maintained until released by operator or triggering device *Easy disconnect for pallet shuttle *Repeatable clamping to 0.0002". Each station delivers up to 7,100 lbs. of clamping force at 4,500 PSI *Each face is controlled separately for convenient part loading and removal *Jaw opening is 4" per station *Each face has a maximum total stroke of 1/4" (1/8" per station) *Jaw options available: Hard jaws, machinable aluminum. machinable ductile iron *Base sizes available: 400mm, 500mm, 630mm *LifetimeIron Clad Warranty

Shipping Info:
*Commercial Truck - Call for Shipping Charges *Actual Weight - 450.0000
