Brand: Widia / Part #: 3641643

Brand: Widia / Part #: 3641643


Item #: 99723678
Brand: Widia
Model #: 3641643

Product Specifications

Thread Type Internal
Hand of Holder Right Hand
Compatible Insert Size Code 2
Shank Width/Diameter (mm) 16.00
Toolholder Style MNNT
Insert Compatibility N.2L
Coolant Entry Style Code 1-Axial Concentric Entry
Insert Holding Method Clamp
Shank Height (mm) 0.00
Shank Length (mm) 150.000
Overall Length (mm) 150.0000
Minimum Bore Diameter (mm) 22.00
Series A-NNT
Multi-use Tool Yes
Cutting Tool Application Grooving; Chamfering; Threading
Maximum Depth of Cut (mm) 4.76
Adjustable Overhang Yes
Back of Bar to Cutting Edge (mm) 19.00
Center to Cutting Edge (mm) 11.00
Insert Inscribed Circle (Decimal Inch) 0.2188
Insert Inscribed Circle (Inch) 7/32
Insert Inscribed Circle (mm) 5.56
Primary Workpiece Material Code P; S; H; K; M; N; O
Coolant Hole Diameter (Decimal Inch) 0.1570
Coolant Hole Thread Size (Inch) 1/8-27 NPT
Toolholder Material Steel
Insert Thickness (Decimal Inch) 0.1500
Style MNNT
Coolant Through Yes
$165.25
