Recoil - Screw-Locking Inserts; Thread Size: M3x0.50 ; Overall Insert Length (mm): 4.50 ; Tang: Yes ; Tang: Tangless ; Length to Diameter Ratio: 1-1/2D ; Length to Diameter Ratio: 1-1/2D
Item #: 91906479
Brand: Recoil
Model #: 15033SF
Product Specifications
Screw-Locking Inserts; Thread Size: M3x0.50 ; Overall Insert Length (mm): 4.50 ; Tang: Yes ; Tang: Tangless ; Length to Diameter Ratio: 1-1/2D ; Length to Diameter Ratio: 1-1/2D
| Thread Size | M3x0.50 |
| Overall Insert Length (mm) | 4.50 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1-1/2D |
| Number of Inserts | 1,000 |
| Minimum Outside Diameter (mm) | 3.80 |
| Maximum Outside Diameter (mm) | 4.35 |
| Number of Free Coils | 6-3/8 |
| Maximum Locking Torque (N/m) | 0.45 |
| Minimum Break Away Torque (N/m) | 0.1000 |
| Thread Standard | Metric Coarse |
