Recoil - Screw-Locking Inserts; Thread Size: #10-24 ; Overall Insert Length (Decimal Inch): 0.1900 ; Tang: Yes ; Tang: Tangless ; Length to Diameter Ratio: 1D ; Length to Diameter Ratio: 1D
Item #: 91906172
Brand: Recoil
Model #: 13602SF
Product Specifications
Screw-Locking Inserts; Thread Size: #10-24 ; Overall Insert Length (Decimal Inch): 0.1900 ; Tang: Yes ; Tang: Tangless ; Length to Diameter Ratio: 1D ; Length to Diameter Ratio: 1D
Thread Size | #10-24 |
Overall Insert Length (Decimal Inch) | 0.1900 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1D |
Number of Inserts | 1,000 |
Minimum Outside Diameter (Decimal Inch) | 0.2440 |
Maximum Outside Diameter (Decimal Inch) | 0.2590 |
Number of Free Coils | 2-7/8 |
Maximum Locking Torque (In/Lb) | 13 |
Minimum Break Away Torque (In/Lb) | 2.00 |
Thread Standard | UNC |
