Iscar - 22IRM Internal Right Hand 7-5 Partial Profile 60° Laydown Threading Insert - Grade IC1007, TiAlN Coated Carbide, 12.7mm Inscribed Circle
Item #: 91126912
Brand: Iscar
Model #: 5903454
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Material | Carbide |
| Insert Style | 22IRM |
| Insert Hand | Right Hand |
| Thread Type | Internal |
| Thread Standard | Partial Profile 60 |
| Material Grade | Submicron |
| Manufacturer's Grade | IC1007 |
| Threads Per Inch | 7-5 |
| Pitch (mm) | 3.50-5.00 |
| Inscribed Circle (mm) | 12.70 |
| Inscribed Circle (Inch) | 1/2 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Thickness (Decimal Inch) | 0.1880 |
| Coating | TiAlN |
| Coating Process | PVD |
| Corner Radius (mm) | 0.19 |
| Corner Radius (Decimal Inch) | 0.0075 |
| Chipbreaker | M |
