Allied Machine and Engineering - 3.543" Max Drill Depth, 2.25xD, 60mm Diam, Indexable Insert Drill - 3 Inserts, 40mm Shank Diam, Straight Shank
Item #: 89539282
Brand: Allied Machine and Engineering
Model #: 11108236
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Drill Style | ECR |
| Drill Diameter (mm) | 60.00 |
| Drill Diameter (Decimal Inch) | 2.3624 |
| Maximum Drill Depth (Decimal Inch) | 3.5430 |
| Shank Type | Straight |
| Shank Diameter (mm) | 40.00 |
| Shank Diameter (Decimal Inch) | 1.5750 |
| Cutting Direction | Right Hand |
| Through Coolant | Through Coolant |
| Drill Depth by Diameter Ratio | 2.25xD |
| Insert Size (Decimal Inch) | 0.7870 |
| Number of Drill Inserts | 3 |
| Maximum Drill Diameter (Decimal Inch) | 1.5750 |
| Overall Length/Projection (Decimal Inch) | 6.8900 |
| Insert Compatibility | XCET 10T304FN-27P; XCET 10T304FN-27Q; XCET 10T308FN-27P; XCET 10T308FN-27Q; XCNT 10T304EN; XCNT 10T304EN-M50Q; XCNT 10T308EN; XCNT 10T308EN-M50Q |
| Flute Length (Decimal Inch) | 3.5430 |
| Body Length (Decimal Inch) | 4.1340 |
| Shank Length (Decimal Inch) | 2.7560 |
| Collar Diameter (Decimal Inch) | 1.9690 |
| Series | EcoCut Rebore |
