Jergens - 1/2" Stroke Len, 0.392 Cu In Volume, 0.785 Sq In Effective Piston Area, Hydraulic, Single Acting, Threaded Body Clamp Cylinder
Item #: 82510215
Brand: Jergens
Model #: 60463
Product Specifications
| Action Type | Single-Acting |
| Operating Stroke Length (Inch) | 1/2 |
| Operating Volume (Cu. In.) | 0.392 |
| Effective Piston Area (Sq. In.) | 0.785 |
| Maximum Operating Pressure (psi) | 5000.00 |
| Minimum Operating Pressure (psi) | 200.00 |
| Maximum Output Force (Lb.) | 3925.00 |
| Body Thread Size | 1-5/16 - 16 |
| Body Thread Length (Inch) | 2 |
| Overall Length (Inch) | 3-1/4 |
| Overall Length (Decimal Inch) | 3-1/4 |
| Operation Type | Hydraulic |
| Projection Length (mm) | 1.59 |
| Projection Length (Inch) | 1/16 |
| Projection Diameter (Inch) | 3/4 |
| Hex Size (Inch) | 1/4 |
| End Port Size | 7/16-20 SAE |
| Side Port Size | 1/8 NPT |
| Rod End Thread Size | 1/4-28 |
| Rod End Thread Depth (mm) | 15.08 |
| Rod End Thread Depth (Inch) | 19/32 |
