Electro Hardware - M5x0.80, 1.5mm Min Panel Thickness, Round Head, Broach Captive Nut - 9.53mm Head Diam, 6.9mm Mounting Hole Diam, 3mm Head Height, Passivated Stainless Steel
Item #: 82142019
Brand: Electro Hardware
Model #: EKFS2-M5-1.5
Exact Tooling IR#: 04
Features and Benefits
Round heads are dome shaped with flat bearing surfaces. They have a higher head height than pan heads.
Stainless steel is a strong, corrosion-resistant alloy with excellent resistance to heat. It is used in high-stress, outdoor and corrosive applications.
| Product Specifications | |
|---|---|
| Type | Broach |
| Head Shape | Round |
| System of Measurement | Metric |
| Thread Size | M5x0.80 |
| Minimum Panel Thickness (mm) | 1.50 |
| Head Diameter (mm) | 9.53 |
| Head Height (mm) | 3.00 |
| Mounting Hole Diameter (mm) | 6.90 |
| Body Diameter (mm) | 7.37 |
| Material | Stainless Steel |
| Material Grade | 18-8 |
| Finish/Coating | Passivated |
| PEM Part Number Equivalent | KFS2-M5-1.5 |
