Square End Mill: 1'' Dia, 4'' LOC, 1'' Shank Dia, 6-1/2'' OAL, 2 Flutes, Solid Carbide Single End, Uncoated, Spiral Flute, 45 ° Helix, Centercutting, RH Cut, RH Flute
Item #: 81760639
Brand: Weldon
Model #: 57472-00-W
Product Specifications
| Mill Diameter (Inch) | 1 |
| Mill Diameter (Decimal Inch) | 1.0000 |
| Number Of Flutes | 2 |
| Length of Cut (Inch) | 4 |
| End Mill Material | Solid Carbide |
| End Type | Single |
| Centercutting | Yes |
| Cutting Direction | Right Hand |
| Shank Diameter (Inch) | 1 |
| Finish/Coating | Bright/Uncoated |
| Overall Length (Inch) | 6-1/2 |
| Helix Angle | 45 |
| Chipbreaker | No |
| Variable Helix | No |
| Variable Index | No |
| Extended Reach | No |
| Length Of Cut Range (Decimal Inch) | 2.0000+ |
| Length of Cut (Decimal Inch) | 4.0000 |
| Material Grade | Micrograin |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Overall Length (Decimal Inch) | 6.5000 |
| Flute Direction | Right Hand |
| Flute Type | Spiral |
| Helix Style | Medium |
| Shank Diameter Tolerance | -0.0001/-0.0005 in |
| Mill Diameter Tolerance | +0.0000/-0.0005 in |
