Indexable Grooving Toolholder: CGWSL12, 1.0000″ Max Depth, Uses 2, 3, 4 & 5 Inserts, 0.7500″ Shank Height, 3/4″ Shank Width, No
Item #: 79985677
Brand: Tungaloy
Model #: 6850093
Product Specifications
| Toolholder Type | External Grooving |
| Insert Seat Size | 0.0790 to 0.1970 in |
| Cutting Direction | Left Hand |
| Maximum Depth of Cut (Decimal Inch) | 1.0000 |
| Minimum Groove Width (Decimal Inch) | 0.0790 |
| Toolholder Style | CGWS |
| Insert Holding Method | Clamp |
| Compatible Insert Size Code | 2; 3; 4; 5 |
| Shank Width/Diameter (Decimal Inch) | 0.7500 |
| Shank Width/Diameter (Inch) | 3/4 |
| Shank Height (Inch) | 3/4 |
| Shank Height (Decimal Inch) | 0.7500 |
| Series | CGWS |
| Shank Length (Decimal Inch) | 5.4000 |
| Overall Length (Decimal Inch) | 5.4000 |
| Cutting Tool Application | Grooving; Recessing; Facing; Threading |
| Head Height (Decimal Inch) | 0.7500 |
| Head Height (Inch) | 3/4 |
| Head Length (Decimal Inch) | 1.3100 |
| Primary Workpiece Material | Universal |
| Toolholder Material | Steel |
| Coolant Through | No |
