Scientific Cutting Tools - 1-5/16 - 12" Port, 1-1/4" Spotface Diam, 1" Tube Outside Diam, Plain Pilot, Carbide Tipped Porting Tool
Item #: 44064970
Brand: Scientific Cutting Tools
Model #: MS33514-16A
Features and Benefits
Carbide-tipped cuts faster than high speed steel. It is commonly used on ferrous and nonferrous materials including cast iron, steel and steel alloys.
| Product Specifications | |
|---|---|
| Port Standard Designation | AS 33514; MS 33514 |
| Pilot Type | Plain |
| Port Thread Size (Decimal Inch) | 1.3120-12 |
| Port Thread Size (Inch) | 1-5/16 - 12 |
| Tool Material | Carbide-Tipped |
| Tube Dash Number | 16.000 |
| Tube Outside Diameter Compatibility (Decimal Inch) | 1.000 |
| Tube Outside Diameter Compatibility (Inch) | 1 |
| Minimum Pilot Diameter (Decimal Inch) | 0.8730 |
| Maximum Pilot Diameter (Decimal Inch) | 1.0180 |
| Spotface Diameter (Decimal Inch) | 1.2500 |
| Pilot Length (Decimal Inch) | 0.5000 |
| Identification Groove | No |
| Workpiece Compatibility | Tubes |
| Finish/Coating | AlTiN+ |
| Head Length (Decimal Inch) | 1.5000 |
| Overall Length (Decimal Inch) | 3.5000 |
| Shank Diameter (Decimal Inch) | 0.7500 |
| Shank Length (Decimal Inch) | 2.0000 |
| Seal Angle | 12 |
| Thread Type | UNJ |
| Flute Type | Straight |
| Number of Flutes | 4 |
