VNMG331EGU YB100 Carbide Turning Insert Al2O3 Finish, 3/8″ Inscribed Circle, 1/64″ Corner Radius, 35° Diamond
Item #: 71965297
Brand: Sumitomo
Model #: 19QK158
Product Specifications
| Insert Style | VNMG |
| Insert Shape Code | V |
| Insert Size Code | 331 |
| Insert Shape | Diamond |
| Clearance Code | N |
| Tolerance Code | M |
| Insert Material | Solid Carbide |
| Manufacturer Grade | YB100 |
| Hole Diameter (Decimal Inch) | 0.1500 |
| Inscribed Circle (Inch) | 3/8 |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Insert Holding Method | Pin; Clamp |
| Insert Hand | Neutral |
| Insert Thickness (Inch) | 3/16 |
| Insert Thickness (Decimal Inch) | 0.1875 |
| Corner Radius (Inch) | 1/64 |
| Corner Radius (Decimal Inch) | 0.0156 |
| Included Angle | 35.0 |
| Relief Angle | 0 |
| Series | VN |
| Coating Process | CVD |
| Rake | Positive |
| Insert Length (Decimal Inch) | 0.6535 |
| Ansi Code | VNMG331EGU |
| Iso Code | VNMG160404N-GU |
| Standards | ISO 13399; ANSI |
| Chip Breaker | EGU |
| Rake Angle | 7 |
| Coating/Finish | Al2O3 |
