Cooper Bussmann - 250 VAC, 32 VDC, 2.5 Amp, Fast-Acting Miniature Glass Fuse - 25.4mm OAL, 10 at 125 V kA Rating, 1/4" Diam
Item #: 71922942
Brand: Cooper Bussmann
Model #: AGX-2-1/2
Exact Tooling IR#: 04
Features and Benefits
Miniature glassfuses are constructed of a conductive metal placed on a small glass body. Fuses with glass bodies are easier to see if they are blown. They are commonly used in appliances and electronics.
Fast acting fuses refer to the amount of time that a fuse can withstand a current before overload. They are used to protect sensitive equipment.
| Product Specifications | |
|---|---|
| Fuse Type | Miniature Glass |
| Amperage | 2.50 |
| Voltage | 250 VAC; 32 VDC |
| Fuse Timing | Fast-Acting |
| Fuse Body Type | Cartridge |
| Overall Length (mm) | 25.40 |
| Overall Length (Decimal Inch) | 1.0000 |
| Overall Diameter (mm) | 6.35 |
| Overall Diameter (Inch) | 1/4 |
| Overall Diameter (Decimal Inch) | 1/4 |
| Material | Glass |
| Interrupting Rating (A) | 100 @ 250 V; 10000 @ 125 V |
| Interrupting Rating (kA) | 10 @ 125 V |
| Standards Met | cULus Recognized Guide JDYX File E 19180; cULus Recognized Guide JDYX7 File E19180; UL Listed 248-14 |
