Cooper Bussmann - 125 VDC, 250 VAC, 25 Amp, Fast-Acting Miniature Ceramic Fuse - 1-1/4" OAL, 1/4" Diam
Item #: 71922405
Brand: Cooper Bussmann
Model #: ABC-25-R
Exact Tooling IR#: 04
Features and Benefits
Miniature ceramic fuses are constructed of a conductive metal placed on a small ceramic body. They are more durable than glass bodies and are commonly used in appliances and electronics.
Fast acting fuses refer to the amount of time that a fuse can withstand a current before overload. They are used to protect sensitive equipment.
| Product Specifications | |
|---|---|
| Fuse Type | Miniature Ceramic |
| Amperage | 25 |
| Voltage | 125 VDC; 250 VAC |
| Fuse Timing | Fast-Acting |
| Fuse Body Type | Cartridge |
| Overall Length (mm) | 31-3/4 |
| Overall Length (Inch) | 1-1/4 |
| Overall Length (Decimal Inch) | 1.2500 |
| Overall Diameter (mm) | 6.35 |
| Overall Diameter (Inch) | 1/4 |
| Overall Diameter (Decimal Inch) | 1/4 |
| Material | Ceramic |
| Interrupting Rating (A) | 1000 @ 250/125 V; 200 @ 250 V; 400 @ 125 V |
| Standards Met | CSA 1422-30 File 53787 Certified; CSA Class 1422-01; MIL-STD-202 Method 204; MIL-STD-202 Method 213; UL Listed 248-14; UL Listed Guide JDYX File E19180; UL Recognized Guide JDYX2 File E19180 |
