Value Collection - Truss Head Steel Structural Blind Rivet - Steel Mandrel, 0.062" to 0.27" Grip, 0.53" Head Diam, 0.191" to 0.201" Hole Diam, 0.415" Length Under Head, 3/16" Body Diam
Item #: 70960679
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Structural rivets are used in structural, limited-clearance applications. They have high strength properties and good resistance to corrosion and tampering.
Truss head types have low-profile heads that are slightly rounded. They have flat bearing surfaces that prevent pull-through and are ideal for low-clearance applications.
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
| Product Specifications | |
|---|---|
| Type | Structural |
| Head Type | Truss |
| Rivet Material | Steel |
| Mandrel Material | Steel |
| Minimum Grip (Decimal Inch) | 0.0620 |
| Maximum Grip (Decimal Inch) | 0.2700 |
| Head Diameter (Decimal Inch) | 0.5300 |
| Minimum Hole Diameter (Decimal Inch) | 0.1910 |
| Maximum Hole Diameter (Decimal Inch) | 0.2010 |
| Length Under Head (Decimal Inch) | 0.4150 |
| Body Diameter (Decimal Inch) | 0.1875 |
| Body Diameter (Inch) | 3/16 |
| Shear Strength (Lb.) | 1300 (Minimum); 1400 (Typical) |
| Tensile Strength (Lb.) | 1000 (Minimum); 1200 (Typical) |
| Head Height (Decimal Inch) | 0.095 to 0.104 |
