Made in USA - 3/4" Diam, 70° Tooth Angle, 50 TPI, Convex, Form Type Cobalt Left-Hand Diagonal Knurl Wheel - 3/8" Face Width, 1/4" Hole, Circular Pitch, Ferritic Nitrocarburizing Finish, Series KPV
Item #: 70100581
Brand: Made in USA
Exact Tooling IR#: 04
Features and Benefits
Left-hand diagonal wheels are designed to produce right-hand diagonal patterns. On a two-wheel knurling tool, left and right diagonal wheels are used together to create a diamond design.
Form wheels produce textured patterns by forming an impression. This process displaces the material and increases the diameter of the workpiece.
Cobalt is harder than high speed steel and provides better wear resistance. It is commonly used on high tensile alloys.
| Product Specifications | |
|---|---|
| Knurl Shape | Convex |
| Pattern | Left-Hand Diagonal |
| Form or Cut Type | Form |
| Material | Cobalt |
| Knurl Diameter (Decimal Inch) | 0.7500 |
| Knurl Diameter (Inch) | 3/4 |
| Face Width (Decimal Inch) | 0.3750 |
| Face Width (Inch) | 3/8 |
| Hole Diameter (Decimal Inch) | 0.2500 |
| Hole Diameter (Inch) | 1/4 |
| Pitch System | Circular |
| Pitch (TPI) | 50 |
| Knurl Series | KPV |
| Included Tooth Angle | 70 |
| Finish/Coating | Ferritic Nitrocarburizing |
