Square D - 600 VAC, 30 Amp, -40 to 275°F, DIN Rail Mount, Nylon Standard Terminal Block - 2 Contacts, Zinc Plated Steel, 22 to 10 AWG Compatibility, 1.76 Inch High x 1.72 Inch Deep
Item #: 69682250
Brand: Square D
Model #: 9080GM6
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Block Type | Standard |
| Mounting Type | DIN Rail Mount |
| Voltage | 600 VAC |
| Amperage | 30 |
| Number of Contacts | 2 |
| Number of Rows | 1 |
| Maximum Compatible Wire Size (AWG) | 10 |
| Minimum Compatible Wire Size (AWG) | 22 |
| Contact Material | Zinc-plated Steel |
| Block Material | Nylon |
| Block Color | Natural |
| Maximum Operating Temperature (F) | 275 |
| Minimum Operating Temperature (F) | -40 |
| Overall Height (Decimal Inch) | 1.7600 |
| Overall Height (mm) | 44.70 |
| Overall Depth (mm) | 43.69 |
| Overall Depth (Decimal Inch) | 1.7200 |
| Overall Width (Decimal Inch) | 0.2400 |
| Overall Width (mm) | 6 |
| Standards Met | CE Marked; CSA Certified File:LR62144 Class 6228 01; RoHS Compliant; UL Listed File:E60616 CCN XCFR2 |
