Schneider Electric - 3 Poles, 500 Volt, 24 Amp, -40 to 266°F, DIN Rail Mount, Polyamide Passthrough Terminal Block - 6 Contacts, 26 to 12 AWG Compatibility, 77-1/2mm High
Item #: 69680189
Brand: Schneider Electric
Model #: NSYTRV26T
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Block Type | Passthrough |
| Mounting Type | DIN Rail Mount |
| Voltage | 500 V |
| Amperage | 24 |
| Number of Contacts | 6 |
| Number of Poles | 3 |
| Number of Rows | 3 |
| Maximum Compatible Wire Size (AWG) | 12 |
| Maximum Compatible Wire Size (sq mm) | 4 |
| Minimum Compatible Wire Size (AWG) | 26 |
| Minimum Compatible Wire Size (sq mm) | 0.14 |
| Block Material | Polyamide |
| Block Color | Gray |
| Maximum Operating Temperature (F) | 266 |
| Minimum Operating Temperature (F) | -40 |
| Overall Height (mm) | 77-1/2 |
| Overall Length (mm) | 90 |
| Overall Width (mm) | 5.20 |
| Standards Met | CSA; GOSTVDE 0304-T21; IEC 60216-1; RoHS Compliant; UL |
