Associated Spring Raymond - 5/16" Bolt, Grade 301 Stainless Steel, Uncoated Curved Disc Spring - 0.077" High, 0.0075" Thick
Item #: 69158897
Brand: Associated Spring Raymond
Model #: U3120075S
Exact Tooling IR#: 04
Features and Benefits
Curved disc springs create a spring-like action and can support heavy loads. They are slightly bent along the outside diameter.
| Product Specifications | |
|---|---|
| Type | Curved Disc Spring |
| Bolt Size (Inch) | 5/16 |
| Bolt Size (mm) | 7.94 |
| System of Measurement | Inch |
| Material | Stainless Steel |
| Material Grade | 301 |
| Thickness (mm) | 0.19 |
| Thickness (Decimal Inch) | 0.0075 |
| Overall Height (mm) | 1.96 |
| Overall Height (Decimal Inch) | 0.0770 |
| Deflection (Decimal Inch) | 0.0360 |
| Deflection (mm) | 0.91 |
| Minimum Inside Diameter (Decimal Inch) | 0.3310 |
| Minimum Inside Diameter (mm) | 8.41 |
| Maximum Outside Diameter (Decimal Inch) | 0.4900 |
| Maximum Outside Diameter (mm) | 12.45 |
| Load at Deflection (Lb.) | 2.25 |
| Load at Deflection (N) | 10.01 |
| Finish/Coating | Uncoated |
| Bolt Size (Decimal Inch) | 5/16 |
