Associated Spring Raymond - 0.516" ID, Grade 1074 High Carbon Steel, Uncoated Finger Disc Spring - 1.004" OD, 1/8" High, 0.007" Thick
Item #: 69139897
Brand: Associated Spring Raymond
Model #: F1004007
Exact Tooling IR#: 04
Features and Benefits
Finger disc springs reduce vibration, noise and skidding in high-speed applications.
| Product Specifications | |
|---|---|
| Type | Finger Disc Spring |
| System of Measurement | Inch |
| Inside Diameter (Decimal Inch) | 0.5160 |
| Inside Diameter (mm) | 13.11 |
| Material | High Carbon Steel |
| Material Grade | 1074 |
| Outside Diameter (Decimal Inch) | 1.0040 |
| Outside Diameter (mm) | 25.50 |
| Thickness (Decimal Inch) | 0.0070 |
| Overall Height (Decimal Inch) | 0.1250 |
| Deflection (Decimal Inch) | 0.0630 |
| Deflection (mm) | 1.60 |
| Minimum Load at Deflection (Lb.) | 6.99 |
| Minimum Load at Deflection (N) | 31.10 |
| Maximum Load at Deflection (Lb.) | 12.99 |
| Maximum Load at Deflection (N) | 57.80 |
| Bearing Outside Diameter (Decimal Inch) | 1.0236 |
| Bearing Outside Diameter (mm) | 26 |
| Number of Fingers | 6 |
| Finish/Coating | Uncoated |
| Overall Height (Inch) | 1/8 |
