Associated Spring Raymond - 180° Deflection Angle, 0.247" OD, 0.021" Wire Diam, 2 Coils, Torsion Spring - 5/32" Max Tool Size, 1 In/Lb Torque at Leg Length
Item #: 69133890
Brand: Associated Spring Raymond
Model #: T021180156L
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Number of Coils | 2.00 |
| Wire Diameter (mm) | 0.53 |
| Wire Diameter (Decimal Inch) | 0.0210 |
| Maximum Tool Size (mm) | 3.96 |
| Leg Length (mm) | 25.40 |
| Deflection Angle | 180 |
| Coil Outside Diameter (mm) | 6.27 |
| Coil Outside Diameter (Decimal Inch) | 0.2470 |
| Leg Length (Decimal Inch) | 1 |
| Maximum Tool Size (Decimal Inch) | 0.1560 |
| Width at Torque (Decimal Inch) | 0.1370 |
| Width at Torque (mm) | 3.48 |
