Associated Spring Raymond - 24.77mm OD, 2.67mm Wire, 25.4mm Free Length, Compression Spring - 101 Lb Spring Rating, 143.18 N Max Work Load, Music Wire
Item #: 69071850
Brand: Associated Spring Raymond
Model #: C09751051000M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 24.77 |
| Outside Diameter (Decimal Inch) | 0.9750 |
| Free Length (mm) | 25.40 |
| Free Length (Decimal Inch) | 1 |
| Spring Rate Pounds per Inch (Pounds) | 101.0000 |
| Maximum Work Load (N) | 143.17999268 |
| Solid Height (mm) | 13.67 |
| Solid Height (Decimal Inch) | 0.5380 |
| Material | Music Wire |
| Wire Size (mm) | 2.67 |
| Wire Size (Decimal Inch) | 0.1050 |
