Associated Spring Raymond - 18.3mm OD, 2.84mm Wire, 76.2mm Free Length, Compression Spring - 88.8 Lb Spring Rating, 309.54 N Max Work Load, Music Wire - USA Tool & Supply

Associated Spring Raymond - 18.3mm OD, 2.84mm Wire, 76.2mm Free Length, Compression Spring - 88.8 Lb Spring Rating, 309.54 N Max Work Load, Music Wire


Item #: 69070225
Brand: Associated Spring Raymond
Model #: C07201123000M
Exact Tooling IR#: 04

Product Specifications
Type Compression
Outside Diameter (mm) 18.29
Outside Diameter (Decimal Inch) 0.7200
Free Length (mm) 76.20
Free Length (Decimal Inch) 3
Spring Rate Pounds per Inch (Pounds) 88.8000
Maximum Work Load (N) 309.54000854
Solid Height (mm) 40.77
Solid Height (Decimal Inch) 1.6050
Material Music Wire
Wire Size (mm) 2.84
Wire Size (Decimal Inch) 0.1120
$3.75
