Associated Spring Raymond - 12.2mm OD, 2.06mm Wire, 1-3/4" Free Length, Compression Spring - 79.2 Lb Spring Rating, 127.05 N Max Work Load, Stainless Steel
Item #: 69062867
Brand: Associated Spring Raymond
Model #: C04800811750X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 44.45 |
| Free Length (Decimal Inch) | 1-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 79.2000 |
| Maximum Work Load (N) | 127.05000305 |
| Solid Height (mm) | 27-1/4 |
| Solid Height (Decimal Inch) | 1.0730 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.06 |
| Wire Size (Decimal Inch) | 0.0810 |
