Associated Spring Raymond - 9.14mm OD, 0.81mm Wire, 1-1/2" Free Length, Compression Spring - 4.5 Lb Spring Rating, 12.94 N Max Work Load, Stainless Steel
Item #: 69047355
Brand: Associated Spring Raymond
Model #: C03600321500S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 38.10 |
| Free Length (Decimal Inch) | 1-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 4.5000 |
| Maximum Work Load (N) | 12.93999958 |
| Solid Height (mm) | 8.74 |
| Solid Height (Decimal Inch) | 0.3440 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.81 |
| Wire Size (Decimal Inch) | 0.0320 |
