Associated Spring Raymond - 12.2mm OD, 1.5mm Wire, 50.8mm Free Length, Compression Spring - 21.8 Lb Spring Rating, 83.4 N Max Work Load, Music Wire
Item #: 69041028
Brand: Associated Spring Raymond
Model #: C04800592000M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 50.80 |
| Free Length (Decimal Inch) | 2 |
| Spring Rate Pounds per Inch (Pounds) | 21.8000 |
| Maximum Work Load (N) | 83.40000153 |
| Solid Height (mm) | 20.57 |
| Solid Height (Decimal Inch) | 0.8100 |
| Material | Music Wire |
| Wire Size (mm) | 1-1/2 |
| Wire Size (Decimal Inch) | 0.0590 |
