Associated Spring Raymond - 6.1mm OD, 1.07mm Wire, 3/4" Free Length, Compression Spring - 53.3 Lb Spring Rating, 39.54 N Max Work Load, Stainless Steel
Item #: 69037034
Brand: Associated Spring Raymond
Model #: C02400420750X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 19.05 |
| Free Length (Decimal Inch) | 3/4 |
| Spring Rate Pounds per Inch (Pounds) | 53.3000 |
| Maximum Work Load (N) | 39.54000092 |
| Solid Height (mm) | 12.67 |
| Solid Height (Decimal Inch) | 0.4990 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.07 |
| Wire Size (Decimal Inch) | 0.0420 |
