Associated Spring Raymond - 6.1mm OD, 0.81mm Wire, 11.18mm Free Length, Compression Spring - 36 Lb Spring Rating, 18.41 N Max Work Load, Stainless Steel
Item #: 69035160
Brand: Associated Spring Raymond
Model #: C02400320440X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 11.18 |
| Free Length (Decimal Inch) | 0.4400 |
| Spring Rate Pounds per Inch (Pounds) | 36.0000 |
| Maximum Work Load (N) | 18.40999985 |
| Solid Height (mm) | 5.31 |
| Solid Height (Decimal Inch) | 0.2090 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.81 |
| Wire Size (Decimal Inch) | 0.0320 |
