Associated Spring Raymond - 20mm Hole Diam, 10mm Rod Diam, 1" Free Length, Green Die Spring - 569.2 N Max Deflection, 10.2mm Max Deflection, Light Duty, Chromium Alloy Steel
Item #: 67898569
Brand: Associated Spring Raymond
Model #: 203-404
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hole Diameter (mm) | 20.00 |
| Rod Diameter (mm) | 10.00 |
| Free Length (mm) | 25.00 |
| Free Length (Inch) | 1 |
| Load Type | Light-Duty |
| Color | Green |
| Maximum Deflection Load (N) | 569.20 |
| Maximum Deflection (mm) | 10.20 |
| Travel To Solid Load (mm) | 10.20 |
| Wire Shape | Trapezoidal |
| Material | Chromium Alloy Steel |
| ISO Number | 10243 |
