Electro Hardware - 0.257" ID x 1/2" OD, 1/4 Screw, Grade 18-8 & 303 Stainless Steel Female Unthreaded Circuit Board Spacer - Round Body, Uncoated, 5/16" OAL
Item #: 67714071
Brand: Electro Hardware
Model #: S1347-M07-F16-K
Exact Tooling IR#: 04
Features and Benefits
Female unthreaded circuit board spacers do not have threads and resemble a plain, cylindrical tube. They are the most common type of spacer.
Stainless steel is a strong, corrosion-resistant alloy with excellent resistance to heat. It is used in high-stress, outdoor and corrosive applications.
| Product Specifications | |
|---|---|
| Type | Female Unthreaded |
| Material | Stainless Steel |
| System of Measurement | Inch |
| Body Shape | Round |
| Screw Size | 1/4 |
| Outside Diameter (Decimal Inch) | 0.5000 |
| Outside Diameter (Inch) | 1/2 |
| Overall Length (Decimal Inch) | 0.3125 |
| Overall Length (Inch) | 5/16 |
| Inside Diameter (Decimal Inch) | 0.257 |
| Finish/Coating | Uncoated |
| Material Grade | 18-8; Grade 303 |
| Inside Diameter Tolerance (Decimal Inch) | 0.000 to 0.010 |
| Length Tolerance (Decimal Inch) | -0.005 to 0.005 |
| Fastener Standard | QQ-S-763 |
