Made in USA - 3/8" ID, 1" Max OD, 3,950 Lb Max Static Cap, Plain Female Spherical Rod End - 3/8-24 RH, 0.687" Shank Diam, 13/16" Shank Length, Carbon Steel with Plastic Raceway
Item #: 67318873
Brand: Made in USA
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Inside Diameter (Decimal Inch) | 0.3750 |
| Inside Diameter (Inch) | 3/8 |
| Style | Plain Female Rod End |
| Maximum Outside Diameter (Decimal Inch) | 1.0000 |
| Maximum Outside Diameter (Inch) | 1 |
| Maximum Static Load Capacity (Pounds) | 3950.0 |
| Width (Inch) | 1/2 |
| Width (Decimal Inch) | 0.5000 |
| Thread Size | 3/8-24 |
| Material | Carbon Steel |
| Shank Diameter (Decimal Inch) | 0.6870 |
| Raceway Material | Plastic |
| Shank Length (Decimal Inch) | 0.8120 |
| Thread Direction | Right Hand |
