Iscar - CNMG332 F3P Grade IC20N Carbide Turning Insert - Uncoated, 80° Diamond, 9.52mm Inscr Circle, 4.76mm Thick, 0.8mm Corner Radius
Item #: 66946674
Brand: Iscar
Model #: 5568445
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | CNMG |
| Insert Size | 332 |
| Material | Carbide |
| Length (mm) | 9.67 |
| Length (Decimal Inch) | 0.3810 |
| Inscribed Circle (mm) | 9.52 |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Thickness (Decimal Inch) | 0.1870 |
| Thickness (mm) | 4.76 |
| Corner Radius (mm) | 0.80 |
| Corner Radius (Decimal Inch) | 0.0310 |
| Manufacturer's Grade | IC20N |
| Coating | Uncoated |
| Chip Breaker | F3P |
| ISO Number | CNMG 332-F3P |
| Rake | Positive |
| Manufacturers Catalog Number | 5568445 |
| Primary Workpiece Material | M; P |
| Secondary Workpiece Material | None |
| Included Angle | 80 |
| Insert Hand | Right Hand |
| Maximum Depth of Cut (mm) | 3.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.1380 |
| Shape | Diamond |
