Seco - Left Hand Cut, Size C4, TN.. 2204.. Insert Compatiblity, External Modular Turning & Profiling Cutting Unit Head - 27mm Ctr to Cutting Edge, 50mm Head Length, Series Seco-Capto
Item #: 60115748
Brand: Seco
Model #: 34021
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| System Size | C4 |
| Series Name | Seco-Capto |
| Cutting Direction | Left Hand |
| Head Length/Projection (mm) | 50.00 |
| Head Length/Projection (Decimal Inch) | 1.9685 |
| Insert Style | TN.. 2204.. |
| Internal or External | External |
| Center to Cutting Edge (mm) | 27.00 |
| Center to Cutting Edge (Decimal Inch) | 1.0630 |
| Insert Holding Method | Clamp |
| Through Coolant | NonThrough Coolant |
| Maximum Hole Depth (mm) | 50.00 |
| Maximum Hole Depth (Decimal Inch) | 1.9685 |
| Minimum Hole Diameter (mm) | 110.00 |
| Minimum Hole Diameter (Decimal Inch) | 4.3307 |
| Neck Diameter (mm) | 40.00 |
| Neck Diameter (Decimal Inch) | 1.5748 |
| Complete Insert Compatibility | TNMA 220408; TNMA 220412; TNMA 220416; TNMG 220404-M5; TNMG 220404-MF2; TNMG 220404-MF3; TNMG 220404-MR4; TNMG 220408-M1; TNMG 220408-M3; TNMG 220408-M5; TNMG 220408-MF2; TNMG 220408-MF3; TNMG 220408-MF4; TNMG 220408-MR4; TNMG 220408-MR6; TNMG 220408-MR7; |
