Gibraltar - 0.0786" Body Length x 3/8" Body Diam, 2.5 Lb Init to 7 Lb Final End Force, Stainless Steel Press Fit Ball Plunger - 5/16" Ball Diam, 0.11" Max Ball Reach, 0.078" Flange Thickness
Item #: 59590737
Brand: Gibraltar
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Body Diameter (Decimal Inch) | 0.3750 |
| Body Length (Decimal Inch) | 0.0786 |
| Body Material | Stainless Steel |
| Ball Material | Stainless Steel |
| Flange | Yes |
| Maximum Ball Reach (Decimal Inch) | 0.1100 |
| Initial End Force (Lb.) | 2.50 |
| Final End Force (Lb.) | 7.00 |
| Length Under Flange (Decimal Inch) | 0.7860 |
| Flange Diameter (Decimal Inch) | 0.5000 |
| Flange Thickness (Decimal Inch) | 0.0780 |
| Ball Diameter (Decimal Inch) | 0.3120 |
| Finish/Coating | Passivate |
| Locking Element | No |
