Gibraltar - 0.394" Body Length x 3/16" Body Diam, 1 Lb Init to 2.5 Lb Final End Force, Steel Press Fit Ball Plunger - 5/32" Ball Diam, 0.058" Max Ball Reach, 0.04" Flange Thickness
Item #: 59590554
Brand: Gibraltar
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Body Diameter (Decimal Inch) | 0.1880 |
| Body Length (Decimal Inch) | 0.3940 |
| Body Material | Steel |
| Ball Material | Stainless Steel |
| Flange | Yes |
| Maximum Ball Reach (Decimal Inch) | 0.0580 |
| Initial End Force (Lb.) | 1.00 |
| Final End Force (Lb.) | 2.50 |
| Length Under Flange (Decimal Inch) | 0.3940 |
| Flange Diameter (Decimal Inch) | 0.2500 |
| Flange Thickness (Decimal Inch) | 0.0400 |
| Ball Diameter (Decimal Inch) | 0.1560 |
| Finish/Coating | Black Oxide |
| Locking Element | No |
