Cle-Force - 7/16-14 UNC 4 Flute Bright Finish Carbon Steel Straight Flute Standard Hand Tap - Taper, Right Hand Thread, 80.17mm OAL, 36.51mm Thread Length, Oversize
Item #: 57635302
Brand: Cle-Force
Model #: C69433
Exact Tooling IR#: 04
Features and Benefits
Taper chamfers also known as starter taps have a longer chamfer and require a less aggressive cutting action. They have 7 to 10 threads.
Carbon steel is a soft, durable metal. It is commonly used for general purpose applications on abrasive materials, nonferrous materials, plastics and wood.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
| Product Specifications | |
|---|---|
| Tap Type | Standard Hand Tap |
| Thread Size (Inch) | 7/16-14 |
| Number of Flutes | 4 |
| Chamfer | Taper |
| Material | Carbon Steel |
| Finish/Coating | Bright |
| Thread Direction | Right Hand |
| Through Coolant | NonThrough Coolant |
| Thread Standard | UNC |
| Overall Length (Decimal Inch) | 3.15620 |
| Overall Length (mm) | 80.17 |
| Oversize | No |
| Series/List | 1696 |
| Thread Length (Decimal Inch) | 1.4375 |
| Thread Length (mm) | 36.51 |
| Shank Diameter (Decimal Inch) | 0.3230 |
| Shank Diameter (mm) | 8.20 |
| Square Size (Decimal Inch) | 0.2420 |
| Square Size (mm) | 6.15 |
