Seco - CCMX060304 E06 Grade HX Carbide Milling Insert - Uncoated, 0.138" Thick, 1/4" Inscribed Circle, 0.016" Corner Radius
Item #: 56974223
Brand: Seco
Model #: 16668
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | CCMX |
| Insert Size | 060304 |
| Material | Carbide |
| Manufacturer's Grade | HX |
| Coating | Uncoated |
| Length (Decimal Inch) | 0.2500 |
| Inscribed Circle (Decimal Inch) | 0.2500 |
| Thickness (Decimal Inch) | 0.1380 |
| Corner Radius (Decimal Inch) | 0.0160 |
| Relief Angle | 7.000 |
| Rake Angle | 15 |
| Rake | Positive |
| Included Angle | 80 |
| Shape | Diamond |
| Chipbreaker | E06 |
| ISO Number | CCMX 060304-E06 |
