Square D - 3,000 VA, Top Mount Fuse Block Control Transformer - 50/60 Hz, 9.15 Inch Deep x 8-3/4 Inch High
Item #: 56795503
Brand: Square D
Model #: 9070T3000D27
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Power Rating (VA) | 3000 |
| Input Voltage | 208/240/480 V |
| Output Voltage | 120 V |
| Frequency Rating (Hz) | 50/60 |
| Mounting Type | Panel |
| Fuse Location | Top Mount Fuse Block |
| Overall Width (Decimal Inch) | 9 |
| Overall Width (mm) | 229 |
| Overall Height (mm) | 222 |
| Overall Height (Decimal Inch) | 8-3/4 |
| Overall Depth (mm) | 232 |
| Overall Depth (Decimal Inch) | 9.1500 |
| Standards Met | CSA File No. LR37055 Guide 184-N-90; cUL Listed E61239; E9579078 EN 61 558/01.89 (TUV Ref:00941-RAG/sg E9471921.02E01); EN:947923 EN 61 558/01.89 (TUV Ref:00941-RAG/sg E9371495E01); EN:9579078 EN 61 558/01.89 (TUV Ref:00941-RAG/sg E9471921E01); ISO 9001; |
