LMT - CCMT060204 Grade LC240T Carbide Milling Insert - TiAlN/TiN Finish, 0.0937" Thick, 1/4" Inscribed Circle, 0.4mm Corner Radius
Item #: 56446776
Brand: LMT
Model #: 89927
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | CCMT |
| Insert Size | 060204 |
| Material | Carbide |
| Material Grade | C5/C6 |
| Manufacturer's Grade | LC240T |
| Coating | TiAlN/TiN |
| Inscribed Circle (Decimal Inch) | 0.2500 |
| Thickness (Decimal Inch) | 0.0937 |
| Corner Radius (Decimal Inch) | 0.0157 |
| Corner Radius (mm) | 0.40 |
| Hole Diameter (mm) | 2.80 |
| Hole Diameter (Decimal Inch) | 0.1102 |
| Relief Angle | 7.000 |
| Coating Process | PVD |
| Included Angle | 80 |
| Shape | Diamond |
