Sandvik Coromant - TN123T3 BG Grade H10F, 3.4mm Cutting Width Cemented Carbide Grooving Insert - 6.4mm Max Depth of Cut, Neutral, Uncoated
Item #: 54927405
Brand: Sandvik Coromant
Model #: 5737082
Exact Tooling IR#: 04
Features and Benefits
Cemented carbide is constructed of hard carbide particles bonded together by a metallic binder. It provides strength, hardness and toughness during the most demanding applications. Cemented carbide also offers maximum resistance to wear, deformation, fracture, corrosion and oxidation.
| Product Specifications | |
|---|---|
| Insert Style | N123T3 |
| Insert Size | T |
| Material | Cemented Carbide |
| Cutting Width (mm) | 3.40 |
| Cutting Width (Decimal Inch) | 0.1339 |
| Maximum Depth of Cut (mm) | 6.40 |
| Maximum Depth of Cut (Decimal Inch) | 0.2520 |
| Manufacturer's Grade | H10F |
| Coating | Uncoated |
| Cutting Direction | Right Hand |
| Insert Hand | Neutral |
| Lead Angle | 0 |
| Relief Angle | 7 |
| Insert Seat Size | T |
| Chipbreaker | BG |
| Multi-Use Tool | Yes |
| Multi-Use Application | Grooving; Profiling |
| Corner Radius (mm) | 0.00 |
| Corner Radius (Decimal Inch) | 0.0000 |
| Series | N123T3 |
| Manufacturers Catalog Number | N123T3-0340-BG H10F |
| Overall Width (mm) | 3.40 |
| Overall Width (Decimal Inch) | 0.1339 |
| Insert Thickness (Decimal Inch) | 0.1470 |
