Walter - NCAI, Internal, Left Hand, 3/4" Max Depth of Cut, 0.236" Max Groove Width, Indexable Grooving Tool Holder - GX24-4.. Insert Compatibility, 2" Shank Width, 14" OAL, Through Coolant
Item #: 52998283
Brand: Walter
Model #: 5029131
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | Internal |
| Toolholder Type | NonFace Grooving |
| Hand of Holder | Left Hand |
| Maximum Depth of Cut (Decimal Inch) | 0.7480 |
| Minimum Groove Width (Decimal Inch) | 0.2360 |
| Maximum Groove Width (Decimal Inch) | 0.2360 |
| Overall Length (Decimal Inch) | 14.0000 |
| Toolholder Style | NCAI |
| Insert Compatibility | GX24-4.. |
| Shank Width/Diameter (Decimal Inch) | 2.0000 |
| Through Coolant | Coolant Through |
| Multi-Use Tool | Yes |
| Multi-Use Application | Threading; Turning |
| Insert Holding Method | Self Clamp |
| Minimum Hole Diameter (Decimal Inch) | 2.3620 |
| Center to Cutting Edge (Decimal Inch) | 1.4170 |
| Head Length (Decimal Inch) | 3.9370 |
| Full Radius Insert | Yes |
| Complete Insert Compatibility | GX24-4E600N030-CE4; GX24-4E600N03-CE4; GX24-4E600N050-GD3; GX24-4E600N050-UA4; GX24-4E600N050-UF4; GX24-4E600N05-GD3; GX24-4E600N05-GD6; GX24-4E600N05-UD6; GX24-4E600N05-UF4; GX24-4E600N080-UF4; GX24-4E600N08-UF4; GX24-4E600N300-RD4; GX24-4E600N30-RD4 |
