KIPP - 5mm Body Length x 4mm Body Diam, 3 N Init to 7 N Final End Force, Stainless Steel Press-Fit Ball Plungers - 0.6mm Max Ball Reach, 1mm Flange Thickness
Item #: 52154689
Brand: KIPP
Model #: K0333.304
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Body Diameter (mm) | 4.00 |
| Body Length (Decimal Inch) | 0.1969 |
| Body Length (mm) | 5.00 |
| Body Material | Stainless Steel |
| Ball Material | Stainless Steel |
| Maximum Ball Reach (mm) | 0.60 |
| Maximum Ball Reach (Decimal Inch) | 0.0236 |
| Initial End Force (N) | 3.00 |
| Initial End Force (Lb.) | 0.67 |
| Final End Force (N) | 7.00 |
| Final End Force (Lb.) | 1.57 |
| Length Under Flange (mm) | 4.00 |
| Flange Diameter (mm) | 4.60 |
| Flange Thickness (mm) | 1.00 |
