Kennametal - RCGK152, KCU10 Grade Carbide Profiling Insert - AlTiN Finish, 50° Incl Angle, Round, 6.59mm Thick, 3/16" Inscribed Circle
Item #: 51666782
Brand: Kennametal
Model #: 4050632
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Material | Carbide |
| Insert Style | RCGK |
| Insert Size | 152 |
| Material Grade | C3/C4 |
| Manufacturer's Grade | KCU10 |
| Inscribed Circle (mm) | 4.76 |
| Inscribed Circle (Inch) | 3/16 |
| Inscribed Circle (Decimal Inch) | 0.1875 |
| Thickness (mm) | 6.59 |
| Thickness (Decimal Inch) | 0.2600 |
| Insert Height (mm) | 6.38 |
| Insert Height (Decimal Inch) | 0.2510 |
| Relief Angle | 8 |
| Coating | AlTiN |
| Coating Process | PVD |
| Chipbreaker | FS |
| Included Angle | 50 |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Series | K-Lock |
| Insert Holding Method | Clamp |
| Shape | Round |
