Iscar - 22UER External Right Hand 4 American Buttress Laydown Threading Insert - Grade IC250, TiCN/TiN Coated Carbide, 12.7mm Inscribed Circle
Item #: 50612381
Brand: Iscar
Model #: 5901444
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Material | Carbide |
| Insert Style | 22UER |
| Insert Hand | Right Hand |
| Thread Type | External |
| Thread Standard | American Buttress |
| Manufacturer's Grade | IC250 |
| External Threads Per Inch | 4 |
| External Pitch (mm) | 4.00 |
| Threads Per Inch | 4 |
| Pitch (mm) | 4.00 |
| Inscribed Circle (mm) | 12.70 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Coating | TiCN/TiN |
| Coating Process | PVD |
| Corner Radius (Decimal Inch) | 0.0160 |
