Telemecanique Sensors - NPN, PNP, NC, 1.5mm Detection, Cylinder, Inductive Proximity Sensor - 2 Wires, IP67, 12 to 48 VDC, M8x1 Thread, 51mm Long
Item #: 49915549
Brand: Telemecanique Sensors
Model #: XS508B1DBL2
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Sensor Type | Inductive |
| Body Shape | Cylinder |
| Sensor Operation Output Mode | NC |
| Output Type | NPN; PNP |
| Connector Type | Cable |
| Number of Wires | 2 |
| Detection Distance (mm) | 1.50 |
| Maximum Voltage | 12-48 VDC |
| Ingress Protection Rating | IP67 |
| Maximum Load Capacity (mA) | 1-1/2 - 100 |
| Response Frequency (Hz) | 4000 |
| Thread Size | M8x1 |
| Housing Material | Stainless Steel |
| Resistance Features | Shock Resistant; Vibration Resistant |
| Overall Length (mm) | 51 |
| Standards Met | CCC; CSA; IEC 60068-2-27; IEC 60068-2-6; IEC 60529; RoHS Compliant; UL |
