Schneider Electric - 1.22 Inch Mount Hole, Extended Straight, Key Operated, Pushbutton Switch with Contact Block - Round, Nonilluminated, Lockable in Extended Position, Dusttight, Oiltight, Watertight and Shock and Vibration Resistant
Item #: 49817778
Brand: Schneider Electric
Model #: 9001KR131H2
Exact Tooling IR#: 04
Features and Benefits
Pushbutton switches with contact blocks are designed to activate machinery by button that is pressed and released. The contact block controls the flow of electricity through the switch.
Nonilluminated pushbuttons do not feature a light within the button.They are commonly used in areas where added light is not needed.
| Product Specifications | |
|---|---|
| Mounting Hole Diameter (mm) | 31 |
| Mounting Hole Diameter (Decimal Inch) | 1.2200 |
| Switch Type | Pushbutton Switches with Contact Blocks |
| Pushbutton Type | Extended (Straight Key Operated) |
| Pushbutton Shape | Round |
| Operator Illumination | NonIlluminated |
| Operation Type | Lockable in Extended Position |
| Pushbutton Material | Metal |
| Amperage | 10 |
| Voltage | 600 VAC |
| Contact Configuration | 2NC/2NO |
| Terminal Type | Screw Clamp |
| NEMA Rating | 1; 2; 3; 4; 12; 13; 3R |
| Resistance Features | Dust-tight; Oiltight; Shock Resistant; Vibration Resistant; Watertight |
| Standards Met | CE Marked; CSA C22.2 No. 14; CSA No. LR25490 Class 3211 03; CSA No. LR26817 Class 3218 02; EN/IEC 60947-1; EN/IEC 60947-5-1; EN/IEC 60947-5-4; JIS C 4520; JIS C 852; RoHS Compliant; UL 508; UL File No. E10054 CCN NOIV; UL File No. E78403 CCN NKCR |
