Sandvik Coromant - M10x1.50 M Metric 6HX Form Thread Forming Tap - High Speed Steel, TiN Finish, 104.64mm OAL, 20mm Thread Length, Right Hand Thread, Series CoroTap 400
Item #: 49627813
Brand: Sandvik Coromant
Model #: 6181719
Exact Tooling IR#: 04
Features and Benefits
Thread forming taps do not cut threads; rather, they form threads by displacing material. They generate threads without producing chips.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
High Speed Steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
| Product Specifications | |
|---|---|
| Thread Size (mm) | M10x1.50 |
| Class of Fit | 6HX |
| Chamfer | Form Tap |
| Finish/Coating | TiN |
| Material | High Speed Steel |
| Overall Length (Decimal Inch) | 4.1197 |
| Overall Length (mm) | 104.64 |
| Thread Standard | M;Metric |
| Thread Length (Decimal Inch) | 0.7874 |
| Thread Length (mm) | 20.00 |
| Series/List | CoroTap 400 |
| Tapping Depth (Decimal Inch) | 1.5354 |
| Tapping Depth (mm) | 39 |
| Thread Direction | Right Hand |
| Shank Diameter (Decimal Inch) | 0.3937 |
| Shank Diameter (mm) | 10.00 |
| Material Application | Non-Ferrous Materials; High Temperature Alloys; Steel; Stainless Steel |
